Meeting the Demands of Harsh Environment Vibration Monitoring
When industrial processes push equipment to the edge, standard sensors often fail. Engineers in power generation, petrochemical, and nuclear facilities require vibration monitoring solutions that withstand extreme heat, radiation, and explosive atmospheres. The Vibro Meter 144-901-000-282 piezoelectric accelerometer delivers exactly that—a robust, certified instrument for the most challenging applications.
This accelerometer is part of the trusted Vibro Meter series, known for proven reliability in critical machinery protection. It meets stringent nuclear standards including NRC guide 1.133 and IEEE 323-1974, and is qualified to DIN 25.475.1, making it a top choice for safety-critical environments.
Technical Specifications and Performance Analysis
The 144-901-000-282 offers a sensitivity of 10 pC/g ±5% at 120 Hz, providing precise charge output for accurate vibration measurement. Its frequency response spans 3 Hz to 2800 Hz within ±5%, with a usable range up to 3700 Hz at less than 10% deviation, ensuring reliable data across a wide spectrum.
With a dynamic measuring range from 0.001 g to 200 g peak and overload capacity up to 500 g peak, this accelerometer handles both subtle vibrations and sudden shock events. Linearity is maintained within ±1% over the entire dynamic range, while transverse sensitivity stays below 5%, minimizing cross-axis errors.
The resonance frequency when mounted exceeds 17 kHz nominal, well above the operating range, preventing structural interference. Internal insulation resistance is a minimum of 10⁹ Ω, and capacitance values are specified for both pole-to-pole and pole-to-casing configurations, ensuring signal integrity.
Extreme Environment Capabilities
This accelerometer excels where others fail. Its continuous temperature range spans -54°C to +650°C, with extreme capability from -196°C to +700°C, making it suitable for cryogenic and high-heat processes alike. The Inconel 600 construction, hermetically welded, provides corrosion and humidity resistance.
Pressure tolerance reaches 140 bar at 23°C and 80 bar at 300°C, ideal for subsea or high-pressure steam applications. Radiation resistance is exceptional: gamma flux up to 10¹¹ erg/g and neutron flux up to 10¹⁸ n/cm² show no effect, qualifying it for nuclear reactor monitoring.
ATEX Certification for Explosive Atmospheres
The 144-901-000-282 carries EC type examination certificate LCIE 08 ATEX 6017 X II 1 G, permitting use in Zones 0, 1, and 2 explosive gas atmospheres. The intrinsic safety rating Ex ia IIC T6 to T710 ensures safe operation in hydrogen and acetylene environments.
Integral case insulation and a two-pole system insulated from the casing provide additional safety. The accelerometer mounts inside a tube using four Allen screws M6 with a fastening torque of 15 Nm, ensuring secure installation in hazardous locations.
Real-World Application Example
In a typical nuclear power plant, the 144-901-000-282 serves as a loose part monitoring accelerometer on reactor coolant pumps. Its extreme temperature range and radiation tolerance allow continuous operation near the reactor core, while the ATEX certification covers any hydrogen buildup in containment areas. The charge output signal connects to a charge converter for remote analysis.
Frequently Asked Questions About the 144-901-000-282
What is the sensitivity of the 144-901-000-282 accelerometer?
The sensitivity is 10 pC/g ±5% at 120 Hz, measured at +23°C ±5°C. This provides a stable charge output proportional to acceleration for precise vibration monitoring.
Can this accelerometer be used in nuclear environments?
Yes, it meets NRC guide 1.133 and IEEE 323-1974, and is qualified to DIN 25.475.1. It withstands gamma flux of 10¹¹ erg/g and neutron flux of 10¹⁸ n/cm² with no effect, making it suitable for nuclear reactor monitoring.
What cable length options are available for the 144-901-000-282?
The ordering number 144-901-000-282 with XX=82 specifies a cable length of 3.5 meters. The transducer uses a Lemo connector and includes a two-pole system insulated from the casing.
