Allen-Bradley 150-F60NBRB 40 HP Solid-State Motor Controller, 60 A, 460 V AC

Product Overview

When your pumping or material handling system demands reliable starting and stopping, the Allen-Bradley 150-F60NBRB delivers precise solid-state control. This Bulletin 150 controller handles 40 HP at 460 V AC, 3-phase, with a robust 60 A rating. Its open enclosure design simplifies integration into existing panels, while the 24V AC/DC control voltage ensures compatibility with modern PLC and safety circuits. Whether you are upgrading an aging starter or designing a new line, this smart motor controller provides the soft-start and braking control your process needs.

Technical Specifications

The 150-F60NBRB operates on an input line voltage of 200..480 V AC, 3-phase, at 50/60 Hz. It delivers maximum horsepower ratings of 15 HP at 200/208 V AC, 20 HP at 230 V AC, and 40 HP at 400/415/460 V AC. For delta-connected motors, it supports up to 30 HP at 200/208 V AC, 40 HP at 230 V AC, and 75 HP at 400/415/460 V AC. In 50 Hz systems, it provides 15 kW at 230 V AC and 30 kW at 400/415/460 V AC. The controller includes pump control options and braking control, making it versatile for diverse industrial applications.

Industry Applications

This controller excels in pump control for water and wastewater facilities, where soft starting reduces mechanical stress on pipes and valves. In conveyor systems, the solid-state design eliminates the wear associated with electromechanical starters. The 150-F60NBRB also suits HVAC fan and compressor applications, where its 24V AC/DC control voltage integrates seamlessly with building management systems. By choosing this model, you gain a reliable solution that minimizes downtime and extends equipment life.

Installation & Setup Guidance

Mount the 150-F60NBRB in a clean, dry enclosure with adequate ventilation. Connect the 3-phase line voltage (200..480 V AC) to the input terminals, and the motor to the output. Use the 24V AC/DC control circuit for start/stop commands. Ensure the motor's full-load current does not exceed 60 A. For pump applications, configure the built-in pump control logic to prevent water hammer. Always follow local electrical codes and the manufacturer's wiring diagram.

Maintenance & Reliability

Inspect the controller periodically for dust accumulation on the heatsink, which can reduce thermal performance. Verify that all power connections remain tight, as loose terminals generate heat. The solid-state design eliminates contact wear, reducing maintenance intervals compared to traditional starters. With proper care, this controller delivers reliable service in demanding environments.

Selection Guide & Purchasing Advice

Before ordering, confirm your motor's voltage and full-load current. The 150-F60NBRB is rated for 60 A continuous and supports motors up to 40 HP at 460 V AC. For delta-connected motors, it handles up to 75 HP at 460 V AC. If your application requires additional features like communication modules or enhanced braking, consult the Bulletin 150 family datasheet. BluePLC Industrial stocks this controller and can advise on compatible accessories. Contact us to verify lifecycle status and availability.
