Schneider TSXSAZ10 AS-Interface Master Module for TSX Micro PLCs

Product Overview

When your automation system requires reliable communication between sensors, actuators, and a PLC controller, the Schneider TSXSAZ10 AS-Interface master module provides a straightforward solution. Designed for the TSX Micro PLCs series, this module acts as the central hub for AS-Interface networks, managing up to 31 server devices. With 4 discrete inputs and 4 discrete outputs, it handles essential I/O tasks without unnecessary complexity. The module integrates seamlessly with the AS-Interface cabling system, reducing wiring errors and installation time.

Technical Specifications Breakdown

The TSXSAZ10 operates with a standard addressing option, ensuring compatibility with typical AS-Interface setups. It supports AS-i version V1 and profile M2, which defines its communication capabilities. The module connects via a terminal block for the AS-Interface line, simplifying field wiring. Power is supplied directly from the host platform, eliminating the need for an external power source. The IP20 rating protects against solid objects larger than 12.5 mm, making it suitable for control cabinets and indoor environments. Operating temperature ranges from 0 to 60 °C, while storage temperature spans -25 to 70 °C. Relative humidity tolerance of 5% to 95% non-condensing ensures reliable performance in varying conditions.

Industry Applications

In material handling systems, the TSXSAZ10 coordinates multiple sensor and actuator devices on a single AS-Interface cable, reducing wiring complexity. For packaging lines, its 4 inputs and 4 outputs handle start/stop signals and status feedback from conveyors and sorters. The module's ability to manage 31 devices makes it effective for medium-sized assembly stations where centralized control is needed. By using the AS-Interface cabling system, engineers save on installation costs and troubleshooting time.

Installation Guide

Mount the TSXSAZ10 in a suitable enclosure with adequate ventilation, respecting the IP20 protection level. Connect the AS-Interface line to the terminal block, ensuring correct polarity and cable type per the AS-Interface cabling system specifications. The module draws power from the host TSX Micro PLC, so verify that the platform's power supply can support the additional load. Configure the addressing using standard AS-Interface tools, setting each slave device to a unique address within the 31-device limit. After wiring, perform a communication test to confirm all devices are recognized.

Maintenance Tips

Inspect the terminal block connections periodically for tightness and signs of corrosion. Keep the module's environment within the specified temperature and humidity ranges to prevent premature failure. Since the TSXSAZ10 has no moving parts, its primary wear point is the electrical connectors. Regularly verify that the AS-Interface cable is not damaged or stressed, as cable faults can cause network interruptions. Following these simple steps extends the module's service life and reduces unplanned downtime.

Compatibility and Integration

The TSXSAZ10 is designed exclusively for the Modicon Premium Automation platform and TSX Micro PLCs series. It works with any AS-Interface V1 compliant slave devices and the AS-Interface cabling system. The module supports standard addressing, making it compatible with most AS-Interface sensors and actuators. For integration, use the host PLC's programming software to configure the module's parameters and map the I/O points. No additional communication protocols are required, simplifying system design.

Buying Guide

Before purchasing the TSXSAZ10, confirm that your host PLC is from the TSX Micro or Modicon Premium series and has an available slot for the module. Verify that your AS-Interface network uses standard addressing and V1 version slaves. The module comes with a terminal block for the AS-Interface line; ensure you have the correct cable and connectors for your installation. BluePLC Industrial offers the TSXSAZ10 with fast shipping and expert support. Contact our team to check current stock and lifecycle status before ordering.
