Schneider TSXCAY41 Motion Control Module for Servo Motors

Product Overview

When motion control precision matters in industrial automation, the Schneider TSXCAY41 delivers reliable performance for servo motor applications. Part of the Modicon Premium Automation platform, this motion control module supports up to four axes, making it a versatile choice for systems requiring coordinated movement. With a power dissipation range of 10 to 17 watts, it balances performance with energy efficiency, reducing thermal stress in control cabinets.

Technical Specifications Breakdown

The TSXCAY41 offers a range of input voltages tailored to different signal types: a 24 V 8 mA auxiliary input, a 24 V 8 mA servo drive control input, and a 5 V 18 mA counter input. Clock frequencies vary by encoder type: the SSI absolute encoder operates at 200 kHz, while incremental encoders can reach 500 kHz in x1 counting mode and up to 1000 kHz in x4 counting mode (250 kHz in input). This flexibility allows the module to handle both high-speed counting and precise positioning tasks.

Input compatibility covers absolute encoders with SSI output (16 to 25 bits) and incremental encoders with 10 to 30 V totem pole or 5 V DC RS422 signals. The module also supports auxiliary inputs for 2-wire/3-wire sensors at 24 V DC. Acquisition speed ranges from 54,000 to 270,000 points per minute, with acceleration times adjustable from 8 ms to 10 s. Resolution spans 0.5 to 1000 position units per point, giving engineers fine control over motion profiles.

Industry Applications

In packaging lines, the TSXCAY41 coordinates servo-driven cutters and conveyors with trapezoidal or parabolic speed profiles, ensuring smooth starts and stops. For material handling systems, its follower axis mode allows one axis to track another at a fixed ratio, simplifying synchronization. The module's automatic and manual operating modes make it suitable for both production runs and maintenance setups.

Installation & Setup Guidance

From a maintenance engineer's perspective, the TSXCAY41's double module format fits standard racks, and its HE-10 and SUB-D connectors simplify wiring. Use the 20-pin HE-10 connectors for servo drive control inputs and auxiliary inputs. The SUB-D 15 connectors handle incremental or absolute encoders, while the SUB-D 9 connector provides the analogue output for speed reference. Always verify input voltage limits: auxiliary and servo drive control inputs accept 19 to 30 V, and the counter input must not exceed 5.5 V. Positive logic is used for all inputs, so plan your sensor wiring accordingly.

Maintenance & Reliability

Reliability is key for continuous operations. The module includes built-in diagnostics with four green LEDs per axis, plus a green RUN LED and red I/O and ERR LEDs for quick fault identification. Output protection features include current limiters and thermal tripping on reflex outputs, plus a Zener diode for overvoltage protection. For long service life, operate the module within its ambient temperature range of 32 to 140 °F (0 to 60 °C) and keep relative humidity between 5 and 95% without condensation. Routine checks of encoder connections and power supply consistency help prevent unexpected downtime.

Compatibility & Integration

The TSXCAY41 integrates seamlessly with the Modicon Premium Automation platform. It supports absolute encoders with SSI output and incremental encoders with RS422 or totem pole interfaces. The module also works with absolute encoder parallel output ABE7CPA11. For control signals, it accepts positive logic DC inputs with resistance up to 15 kOhm on reflex outputs. This compatibility makes it a straightforward upgrade or replacement for existing motion control setups.

Selection Guide & Purchasing Advice

Before ordering, confirm your system's encoder type and voltage requirements. The TSXCAY41 handles both SSI and incremental encoders, but check that your encoder's output matches the module's input compatibility. Also verify the required number of axes (up to four) and the operating mode (automatic, manual, follower, or direct drive). BluePLC Industrial stocks the TSXCAY41 and can help verify compatibility with your existing Modicon Premium system. Contact us for current availability and lifecycle status.
