Schneider TSXCANCBDD03 CANopen Cordset with SUB-D9 Connectors, 0.3m

Product Overview

When your CANopen bus network demands reliable and compact connections, the Schneider TSXCANCBDD03 delivers a ready-to-use solution. This CANopen cordset features molded female SUB-D9 connectors, ensuring secure data transmission in space-constrained industrial environments. Part of the CANopen range, it is designed for seamless integration into Schneider automation systems.

Technical Specifications

The TSXCANCBDD03 offers key parameters that define its performance:

Product Type: CANopen cordset

Bus Type: CANopen

Cable Length: 1.0 ft (0.3 m)

Electrical Connection: 2 female connectors SUB-D 9

IP Degree of Protection: IP20

Product Certifications: UL

Marking: CE

Product Weight: 0.190 lb(US) (0.086 kg)

These specifications ensure the cordset meets standard industrial requirements for communication and durability.

Industry Applications

The TSXCANCBDD03 excels in applications requiring short, reliable CANopen connections. Use it to connect field devices, sensors, or actuators to a CANopen bus in manufacturing lines, packaging machinery, or material handling systems. Its compact 0.3 m length reduces cable clutter in control panels and junction boxes. Compared to longer cables or field-assembled connectors, this molded cordset provides a factory-tested, robust solution that minimizes installation errors and signal degradation.

Installation & Setup Guidance

Installing the TSXCANCBDD03 is straightforward. Connect the two female SUB-D9 connectors to compatible male ports on your CANopen devices. Ensure the cordset is routed away from high-voltage cables to avoid electromagnetic interference. The IP20 rating makes it suitable for clean, dry indoor environments. No special tools are required for installation.

Maintenance & Reliability

The molded construction of the TSXCANCBDD03 enhances reliability by protecting internal connections from dust and mechanical stress. For long-term performance, inspect the connectors periodically for signs of wear or corrosion. The UL certification confirms compliance with safety standards, supporting dependable operation in industrial settings.

Compatibility & Integration

This cordset is designed for the CANopen bus protocol, making it compatible with Schneider Electric PLCs, drives, and I/O modules that support CANopen. It also works with third-party CANopen devices using standard SUB-D9 interfaces. Verify your device's connector type and pinout before ordering to ensure seamless integration.

Selection Guide & Purchasing Advice

Before purchasing the TSXCANCBDD03, confirm your required cable length and connector configuration. This model offers a fixed 0.3 m length with two female SUB-D9 connectors. If you need a different length or connector type, explore other options in the CANopen cordset range. BluePLC Industrial stocks this item and can assist with availability and lifecycle status. Please verify current lifecycle status and availability with BluePLC Industrial before ordering.
