Schneider TSX3710101 Micro PLC for Versatile Automation

Product Overview

When you need a compact yet powerful controller for diverse automation tasks, the Schneider TSX3710101 from the TSX Micro PLCs series delivers reliable performance. This micro PLC operates within a 100-240 V AC voltage range and supports input currents from 2 mA up to 60 A, adapting to various project demands. With a robust design, it handles environments from 32 to 140 °F (0 to 60 °C) and humidity levels of 10% to 95% without condensation.

Technical Specifications Breakdown

The TSX3710101 offers 8 analog input slots with a 0 to 10 V range and 1 analog output slot supporting the same voltage range. Its output capacity reaches a maximum of 0.5 A. Memory includes 15 Kwords of flash memory and 20 Kwords of internal RAM, expandable to 128 Kwords via a PCMCIA card. Execution times range from 0.13 µs for Boolean operations to 4.5 µs for arithmetic REAL floating operations. The application structure supports 1 fast task, 1 master task, and 16 event tasks, enabling efficient process management.

Industry Applications

In manufacturing lines, the TSX3710101 controls analog sensors and actuators with precision, thanks to its 8 analog inputs and 1 analog output. For building automation, its dual communication interfaces—1 serial link (TER/AUX) Uni-Telway at 19.2 kbit/s and 1 Modbus RTU at 19.2 kbit/s—allow seamless integration with supervisory systems. The wide input current range (2 mA to 60 A) makes it suitable for applications with varying power demands.

Compatibility & Integration

The TSX3710101 communicates via Modbus RTU and Uni-Telway, both rated at 19.2 kbit/s. This enables connection to Schneider PLCs, HMIs, and SCADA systems. The 2 expansion slots allow modular growth, and the PCMCIA memory expansion supports larger programs. This integration flexibility reduces engineering effort and speeds up deployment.

Selection Guide & Purchasing Advice

Before ordering, verify that your application requires a micro PLC with 8 analog inputs and 1 analog output. The TSX3710101 operates on 100-240 V AC at 50/60 Hz. For current availability and lifecycle status, contact plcmatrix.com, a trusted supplier of industrial automation components. They offer new, surplus, and obsolete parts from leading brands.

Comparison with Similar Models

Compared to other micro PLCs in the TSX Micro family, the TSX3710101 stands out with its 8 analog input slots and 1 analog output slot. While some models offer fewer I/O or lack analog outputs, this unit provides balanced analog I/O for process control. Its dual communication interfaces (Uni-Telway and Modbus RTU) also exceed the single-port options found on entry-level units.
