Schneider Modicon PC-A984-130 32-bit RISC Processor 200 MHz 512 KB Flash

Product Overview

When industrial automation demands reliable processing power, the Schneider Modicon PC-A984-130 delivers a robust solution. This processor, part of the Modicon family, operates on a 32-bit RISC architecture at 200 MHz and includes 512 KB of Flash memory for efficient data storage and retrieval. It is designed for panel mounting and requires a stable 24V DC power supply, making it suitable for a wide range of industrial control applications.

Technical Specifications Breakdown

The PC-A984-130 offers key specifications that ensure dependable performance. The 32-bit RISC processor at 200 MHz provides fast instruction execution for complex logic tasks. With 512 KB of Flash memory, the unit stores critical programs and data securely. Communication is handled through RS-232, RS-485, and Ethernet ports, enabling seamless integration into existing networks. The IP20 protection rating guards against solid objects larger than 12.5 mm, while the operating temperature range of 0°C to 50°C ensures stable operation in typical industrial environments. Additionally, the device withstands shock up to 10 g for 11 ms and vibration at 1 g from 10 to 500 Hz, confirming its durability.

Industry Applications

This processor excels in discrete manufacturing and process control applications where reliable logic execution and communication are critical. For example, in packaging lines, the PC-A984-130 coordinates multiple machines using its Ethernet port for real-time data exchange. In material handling systems, its RS-485 port allows connection to remote I/O modules over long distances. The 32-bit RISC architecture ensures fast response times, reducing cycle times and improving throughput.

Installation & Setup Guidance

Mount the PC-A984-130 on a panel using the provided mounting slots. Ensure the power supply delivers a stable 24V DC within the specified range. Connect communication cables to the RS-232, RS-485, or Ethernet ports as needed for your network topology. Verify that the operating environment stays within 0°C to 50°C and humidity between 10% and 95% RH to avoid performance issues. Use shielded cables for Ethernet to minimize electromagnetic interference.

Maintenance & Reliability

Routine inspection of the PC-A984-130 should focus on checking for dust accumulation on the IP20-rated enclosure and ensuring ventilation openings remain clear. Verify that all cable connections are secure and free from corrosion. The device's shock and vibration resistance (10 g shock, 1 g vibration) reduces the risk of failure in harsh industrial settings. Periodic firmware updates, if available, can enhance functionality and security. Following these practices extends the service life and maintains system reliability.

Compatibility & Integration

The PC-A984-130 integrates with Modicon and other automation systems via its RS-232, RS-485, and Ethernet ports. It supports standard industrial protocols over these interfaces, allowing connection to PLCs, HMIs, drives, and sensors. For new installations, verify that the 24V DC power supply is compatible and that the panel mount orientation meets clearance requirements. BluePLC Industrial offers this processor along with compatible accessories to simplify your procurement.

Selection Guide & Purchasing Advice

Before ordering the PC-A984-130, confirm that your system requires a 32-bit RISC processor with 512 KB Flash memory and the communication ports listed. Check the operating temperature range (0°C to 50°C) and storage temperature (-20°C to 70°C) to ensure it matches your facility conditions. BluePLC Industrial stocks this Schneider Modicon processor and can provide current lifecycle status and availability. Contact our team for assistance with your specific application needs.
