Schneider BMXP3420302CL Modicon M340 Processor Module Overview

Product Introduction

When you need a reliable processor for mid-range automation, the Schneider BMXP3420302CL from the Modicon M340 platform delivers. This module handles up to 1024 discrete I/O and 256 analog I/O in multi-rack configurations, making it suitable for complex machinery and process control. It integrates CANopen and Ethernet TCP/IP communication, and requires a memory card (not supplied) to operate.

Technical Specifications Breakdown

The BMXP3420302CL offers key performance metrics. It supports up to 4 racks and 11 slots, with a discrete I/O capacity of 1024 I/O in multi-rack or 704 I/O in single-rack setups. Analog I/O capacity reaches 256 I/O in multi-rack or 66 I/O in single-rack configurations. Execution times are 0.12 µs for Boolean instructions and 1.16 µs for floating points. The module consumes 135 mA at 24 V DC and weighs 0.215 kg.

Industry Applications

This processor excels in manufacturing lines, packaging systems, and material handling. Its CANopen master bus supports up to 63 devices, enabling coordinated motion control and sensor networks. The Ethernet TCP/IP port allows seamless integration with SCADA and MES systems for data logging and remote monitoring.

Installation & Setup Guidance

Mount the BMXP3420302CL on a Modicon M340 rack using the internal power supply. Insert a compatible memory card before powering up. Connect the CANopen bus via the SUB-D 9 connector and Ethernet via the RJ45 port. Configure the processor using Unity Pro software, setting up master tasks and communication parameters as needed.

Compatibility & Integration

The BMXP3420302CL works with Modicon M340 racks and I/O modules. It supports up to 2 Ethernet communication modules and 4 AS-Interface modules. Embedded services include CANopen network management, Modbus TCP messaging, and SNMP network administration. The USB port at 12 Mbit/s aids local programming.

Selection Guide & Purchasing Advice

Before ordering, verify that your system requires a Modicon M340 processor with CANopen and Ethernet. Ensure you have a compatible memory card and rack. BluePLC Industrial offers this Schneider BMXP3420302CL module with fast shipping and expert support. Please verify current lifecycle status and availability with BluePLC Industrial before ordering.
