Schneider ABFS16H200 Modicon Quantum Connecting Cable 2m 16-Conductor

Product Overview

In industrial automation, reliable signal transmission is critical for system accuracy and uptime. The Schneider ABFS16H200 connecting cable delivers dependable analog I/O connectivity for Modicon Quantum systems. This 2-meter cable features 16 conductors with HE-16 connectors, ensuring secure and consistent data exchange in demanding environments.

Technical Specifications

The ABFS16H200 is built with precision for industrial use. Key specifications include:

Cable Length: 2 meters

Number of Conductors: 16 conductors

AWG Gauge: AWG 22

Current Rating: 2 A

Voltage Rating: 250 V

Connector Type: HE-16

Connector Pitch: 5 mm

Signal Type: Analog I/O

Insulation Material: PVC

Cable Construction: Multi-conductor shielded cable

Operating Temperature Range: -20 °C to +60 °C

Humidity Tolerance: 95% relative humidity, non-condensing

Compliance: RoHS compliant

These specifications make the ABFS16H200 suitable for a wide range of analog signal applications within the Modicon Quantum ecosystem.

Industry Applications

The ABFS16H200 is ideal for use in manufacturing plants, process control systems, and infrastructure automation where Modicon Quantum controllers manage analog inputs and outputs. Its shielded construction minimizes electromagnetic interference, preserving signal integrity in electrically noisy environments. The 2-meter length provides flexibility for cabinet wiring without excessive slack.

Installation & Setup Guidance

Installation is straightforward thanks to the plug-and-play design. Simply connect the HE-16 connectors to the corresponding modules on your Modicon Quantum system. Ensure the cable is routed away from high-voltage power lines to avoid noise coupling. The 5 mm connector pitch aligns with standard Quantum I/O modules, making replacement or upgrades simple.

Maintenance & Reliability

Routine inspection of the ABFS16H200 cable and connectors is recommended to ensure secure connections and detect any physical damage. The PVC insulation and shielded construction provide durability against typical industrial wear. Operating within the -20 °C to +60 °C temperature range and up to 95% humidity ensures long-term reliability in various conditions.

Compatibility & Integration

The ABFS16H200 is designed specifically for the Modicon Quantum series by Schneider Electric. It works seamlessly with Quantum analog I/O modules that accept HE-16 connectors. Always verify compatibility with your specific module part numbers before ordering.

Selection Guide & Purchasing Advice

When selecting the ABFS16H200, confirm your system requires a 2-meter cable with 16 conductors for analog signals. If you need different lengths or conductor counts, consult the Modicon Quantum cable family. BluePLC Industrial offers the ABFS16H200 with reliable availability and support for your automation needs.
