Schneider 690MCI00006 Modicon Module: 600V AC/DC, 10A, 4.5 kW

Product Overview

When your industrial application demands reliable power handling and robust connectivity, the Schneider 690MCI00006 from the Modicon series delivers. This component supports a rated voltage of 600V AC/DC and a rated current of 10.00 A, making it a versatile choice for various electrical environments. Its nominal power of 4.5 kW and frequency range of 50/60 Hz ensure consistent performance in standard industrial settings.

Technical Specifications

The 690MCI00006 operates with a rated voltage of 600V AC/DC and a rated current of 10.00 A. It provides a nominal power of 4.5 kW and handles frequencies from 50 to 60 Hz. The unit can withstand overload conditions of 120% for 30 minutes, offering resilience during peak loads. Its operating temperature range spans -10°C to +60°C, while storage temperature ranges from -20°C to +70°C. The IP20 degree of protection suits indoor control environments. Vibration resistance is rated at 1g for 10-55 Hz, ensuring stability in moderate vibration conditions.

Industry Applications

This module excels in industrial control panels, motor control centers, and automation systems where 600V AC/DC circuits are common. Its 3-meter multi-core shielded copper cable reduces electromagnetic interference, making it suitable for sensitive signal environments. The push-in terminal block connector simplifies wiring in high-density panels. With DIN rail mounting, installation is quick and secure in standard enclosures.

Installation & Setup Guidance

Mount the 690MCI00006 on a standard DIN rail in a clean, dry indoor location. Use the push-in terminal block for secure wire connections. Ensure the cable diameter does not exceed 8 mm. Verify that the operating environment stays within -10°C to +60°C and that the IP20 enclosure protects against solid objects. Follow standard wiring practices for 600V AC/DC circuits.

Maintenance & Reliability

Periodically inspect the cable for wear and the terminal connections for tightness. Keep the unit free from dust and moisture to maintain IP20 protection. The 120% overload capacity for 30 minutes provides a safety margin during temporary surges. Regular checks of the operating temperature and vibration levels help extend service life.

Buying Guide

Before purchasing, confirm that your system requires 600V AC/DC rated voltage and 10.00 A current capacity. Verify the DIN rail mounting compatibility and the 3-meter cable length meets your layout needs. BluePLC Industrial offers the Schneider 690MCI00006 with fast shipping and expert support. Contact us for current availability and lifecycle information.
