Schneider 140NWM10000C Modicon Quantum Operator Panel with LED Display

Product Overview

The Schneider Electric 140NWM10000C is a dedicated operator panel within the Modicon Quantum series. It features a clear LED display for user interaction in industrial control systems. This panel offers two communication ports with MT-RJ and RJ-45 connectors, enabling flexible connectivity. Designed for cost-effective human-machine interface, it reduces installation complexity and long-term expenses.

Technical Specifications

Display Type: LED

Number of Connection Ports: 2

Connector Types: MT-RJ, RJ-45

Standards Compliance: CE

Protection Class: IP20

Enclosure Rating: NEMA 1

Maximum Ambient Temperature: 40 degrees Celsius

Minimum Ambient Temperature: 0 degrees Celsius

Maximum Operating Humidity: 80% RH, non-condensing

Maximum Storage Humidity: 80% RH, non-condensing

Maximum Operating Altitude: 1000m above sea level

These parameters ensure reliable operation in typical indoor industrial environments, reducing downtime and maintenance costs.

Industry Applications

The 140NWM10000C suits manufacturing lines, process control, and building automation where operators need clear status feedback. Its LED display provides instant readability, minimizing operator errors and improving efficiency. The IP20 and NEMA 1 ratings make it ideal for clean indoor settings, avoiding costly enclosure upgrades.

Installation & Setup

Mount the panel in a dry, indoor location within the specified temperature range (0 to 40 degrees Celsius). Use the MT-RJ or RJ-45 ports for network connections. Ensure proper cable strain relief to maintain reliable communication. No special tools are required, reducing labor costs.

Maintenance & Reliability

The robust design with IP20 protection and NEMA 1 enclosure reduces dust ingress. Periodic visual inspection of connectors and display is recommended. Operating within the 0 to 40 degrees Celsius range and below 80% RH humidity extends service life, lowering total cost of ownership.

Compatibility & Integration

As part of the Modicon Quantum family, this operator panel integrates seamlessly with Schneider control systems. The dual-port design supports standard industrial Ethernet connections via RJ-45 or fiber via MT-RJ, offering deployment flexibility without extra adapters.

Selection Guide & Purchasing Advice

Before ordering, verify that your system uses Modicon Quantum architecture and that ambient conditions stay within the 0 to 40 degrees Celsius range. The 140NWM10000C is a cost-effective choice for new installations or upgrades. Contact BluePLC Industrial for current availability and lifecycle status.
