Honeywell U4205-60001 34-Channel Single-Ended Mictor Connector Probe for Logic Analyzers

Product Overview

When debugging complex digital circuits, engineers often struggle with signal integrity and probe connectivity. The Honeywell U4205-60001 single-ended Mictor connector logic analyzer probe solves this challenge. With 34 channels and direct connect capability, this probe ensures reliable data and clock signal capture for your logic analyzer setup.

Designed for use with the 16850A Series portable logic analyzers, the U4205-60001 provides a robust interface between your test equipment and the device under test. Logic analyzer probes are ordered separately, so specify this probe when ordering to guarantee the correct connection.

Key Specifications

The U4205-60001 features 34 channels for single-ended data and clock signals. Its direct connect design minimizes signal degradation and simplifies setup. This probe is specifically compatible with Keysight 16850A Series portable logic analyzers, ensuring seamless integration into existing test environments.

Industry Applications

In R&D labs, engineers use the U4205-60001 to capture high-speed digital signals from microcontrollers, FPGAs, and ASICs. Its 34-channel capacity allows simultaneous monitoring of multiple data lines and clocks, making it invaluable for protocol analysis and timing verification. For field service teams, the direct connect feature reduces setup time, enabling faster troubleshooting of digital systems.

Installation & Setup Guidance

To use the U4205-60001, connect the Mictor connector directly to the target board's header. Ensure the probe orientation aligns with the header's keying to avoid pin damage. Pair the probe with a compatible 16850A Series logic analyzer and configure the channel mapping in the analyzer software. Verify signal integrity by checking the probe's connection before starting data capture.

Maintenance & Reliability

Regularly inspect the Mictor connector for bent pins or debris. Clean the connector contacts with a lint-free cloth and isopropyl alcohol if needed. Store the probe in a static-safe bag when not in use to prevent ESD damage. These practices extend the probe's service life and maintain signal quality.

Selection Guide & Purchasing Advice

Before purchasing, confirm that your logic analyzer model is compatible with the U4205-60001. This probe works with Keysight 16850A Series analyzers. For other models, check the connector type and channel count. BluePLC Industrial offers the U4205-60001 with fast shipping and expert support. Contact our team to verify availability and ensure this probe meets your testing needs.
