Honeywell 800-336-2112 MOOG Slip Coil Ring Assembly – 10 Amp 12 Channel

Product Overview

When rotating equipment demands uninterrupted power and signal transmission, the Honeywell 800-336-2112 MOOG Slip Coil Ring Assembly delivers a robust solution. This slip ring coil assembly is engineered for continuous rotation applications where reliability directly impacts uptime and operational costs. With a 10 Amp rating and 12 channels, it supports multiple circuits in a single compact assembly, reducing installation complexity and maintenance overhead.

Technical Specifications

The 800-336-2112 is built around two key performance parameters that define its capability:

10 Amp Rating: This current capacity ensures the assembly can handle moderate power loads without overheating, translating to longer service life and fewer replacements. For operators, this means lower total cost of ownership as downtime for repairs is minimized.

12 Channels: Twelve independent channels allow simultaneous transmission of power and signals, enabling complex control systems to operate through a single rotating interface. This consolidation reduces wiring costs and simplifies troubleshooting.

These specifications make the assembly a cost-effective choice for applications where multiple signals must pass through a rotating joint without interference.

Industry Applications

The 800-336-2112 excels in environments where continuous rotation is essential. Typical applications include:

Rotary Indexing Tables: In automated assembly lines, the 12-channel configuration supports sensors, actuators, and power delivery, reducing the need for multiple slip rings and cutting installation costs by up to 30%.

Wind Turbine Pitch Control: The 10 Amp rating reliably powers pitch adjustment motors while signal channels transmit position feedback, ensuring efficient energy capture and reducing unplanned maintenance expenses.

Packaging Machinery: Rotating turrets in filling and capping machines benefit from the assembly's compact design, which simplifies integration and lowers material costs.

Installation & Setup Guidance

Proper installation of the 800-336-2112 ensures maximum performance and longevity. Mount the assembly on a clean, dry shaft and secure it using the provided hardware. Align the rotor and stator carefully to avoid binding, which can cause premature wear. Verify that all 12 channels are connected per the system wiring diagram before applying power. For best results, use shielded cables for signal lines to minimize electrical noise. BluePLC Industrial recommends consulting the Honeywell installation manual for torque specifications and clearance requirements.

Maintenance & Reliability

Regular inspection of the slip ring assembly extends its operational life and protects your investment. Check for signs of brush wear or debris buildup every 6 months in clean environments, or more frequently in dusty or humid conditions. The 10 Amp continuous rating allows a safety margin for transient loads, reducing the risk of thermal damage. By following a preventive maintenance schedule, operators can avoid unexpected failures and the associated costs of emergency repairs and production losses.

Selection Guide & Purchasing Advice

Before purchasing the 800-336-2112, verify that the 12-channel configuration matches your system's signal and power requirements. Confirm the shaft diameter and mounting style are compatible with your rotating equipment. For applications exceeding 10 Amps per channel, consider a higher-rated model. BluePLC Industrial stocks the Honeywell 800-336-2112 MOOG Slip Coil Ring Assembly and can provide technical support to ensure you select the right component for your system. Contact our team to discuss volume pricing and lead times.

Please verify current lifecycle status and availability with BluePLC Industrial before ordering.
