GE IC695ETM001 Ethernet Interface Module for PACSystems RX3i

Introduction to the GE IC695ETM001

When your industrial network demands reliable Ethernet connectivity, the GE IC695ETM001 Ethernet interface module delivers. Part of the PACSystems RX3i family, this single-slot module provides two RJ45 ports supporting 10/100 Mbps transmission rates with auto-negotiation. It enables seamless communication between your RX3i controller and other platforms like Series 90 and VersaMax controllers.

Key Technical Specifications

Ethernet Ports: 2x 10/100 Mbps

Serial RS-232: Yes, with data rates from 1200 bps to 115200 bps

Hot-swappable: Yes, with firmware revision 2.51

Autosensing Ports: Yes

Ethernet Processor Speed: 200 MHz

Non-volatile Memory: Yes – Allows daisy-chaining of Ethernet nodes

Duplex Modes: Half and full duplex

Ethernet Connectors: 8-pin female shielded RJ45

Serial Connector: 9-pin female D-connector

Industry Applications

Manufacturing Plant Networking

In a multi-line manufacturing environment, the IC695ETM001 connects RX3i controllers to a plant-wide Ethernet network. Its support for SRTP, Modbus TCP, and EGD protocols allows data exchange with other controllers and SCADA systems. The hot-swappable design minimizes downtime during maintenance or expansion.

Process Control Integration

For process industries like oil and gas, the module's RS-232 serial port provides an alternative communication path for legacy equipment. The Station Manager function offers supervisory access for diagnostics and configuration, ensuring smooth integration with existing systems.

Installation & Setup Guidance

Install the IC695ETM001 into any empty slot on a compatible RX3i backplane such as IC695CHS007, CHS012, or CHS016. The module supports insertion under power or when the processor is in RUN mode, enabling hot-swap capability. Ensure firmware revision 2.51 is installed for hot-swap functionality. Use standard Ethernet cables with RJ45 connectors for network connections and a 9-pin female D-connector for serial communication.

Maintenance & Reliability

Routine inspection of the module's LED status indicators—Ethernet OK, LAN OK, Log Empty, and individual port/speed LEDs—helps verify proper operation. The non-volatile memory retains configuration during power cycles, enhancing reliability. For long-term performance, keep the module firmware updated using GE Fanuc software tools.

Compatibility & Integration

The IC695ETM001 is compatible with any PACSystems RX3i module except the CPE400. It communicates with Series 90 and VersaMax controllers using SRTP, Modbus TCP, and EGD protocols over a four-layer TCP/IP stack. The embedded switch supports auto-negotiation, speed sensing, and crossover detection. Use the module for time synchronization via SNTP to an SNTP Time Server on Ethernet TCP/IP.

Selection Guide & Purchasing Advice

Before purchasing the IC695ETM001, verify your backplane compatibility and required firmware version. This module is ideal for upgrading existing RX3i systems or building new networks needing dual Ethernet ports and serial connectivity. For current availability and lifecycle status, contact plcmatrix.com. They offer new, surplus, and obsolete industrial automation parts from leading brands.

For complete technical specifications for the IC695ETM001, please contact plcmatrix.com.
