GE IC200MDL742 Versamax Discrete Output Module Buyer's Guide

Product Introduction

When your industrial application requires reliable discrete output control, the GE IC200MDL742 discrete output module delivers. This module is part of the GE Fanuc Versamax series and provides 16 discrete outputs in 2 groups. It uses 24 Volts DC positive logic and is designed for sinking type output points. The module includes short circuit and overcurrent protection, along with free-wheeling diodes for added reliability.

Technical Specifications Breakdown

Understanding the key specifications helps you evaluate if this module fits your system. The IC200MDL742 has an output voltage range of 18 to 30 Volts DC, with 24 Volts DC nominal. It consumes 150 milliamps of backplane current at 5 Volts. The module offers group-to-group isolation of 250 Volts AC continuous and 1500 Volts AC for 1 minute. Each output point has a dedicated LED indicator, and there are additional "OK" and "FLD PWR" LEDs for status monitoring. The module ID is 80808080.

Industry Applications

The IC200MDL742 is suitable for general-purpose discrete output control in manufacturing, packaging, and material handling systems. Its 16 outputs in 2 groups allow flexible wiring for loads such as solenoids, indicator lights, and small relays. The short circuit and overcurrent protection reduce downtime by preventing damage from wiring faults. In applications where field power may be interrupted, an external power supply can maintain output voltage during short circuit conditions. Batteries or capacitors can serve as local energy storage to supplement power.

Installation & Setup Guidance

Mount the IC200MDL742 on a DIN rail using compatible carrier types. The module supports any orientation, simplifying panel layout. Connect field power to the DC+ and DC- terminals for each group. The 32 output points are divided into 2 groups, each with 16 points. Ensure the external power supply meets the energy requirements for short circuit situations. The module supports hot insertion, allowing quick connection to an industrial application without powering down the entire system.

Compatibility & Integration

The IC200MDL742 is compatible with a wide range of I/O modules, host controllers, and PLCs within the Versamax ecosystem. It receives 32 bits of output data, with intelligent processing handled by the CPU. This module can be used to create a standalone I/O station. Verify compatibility with your specific controller before ordering.

Selection Guide & Purchasing Advice

Before purchasing the IC200MDL742, confirm that your system requires a 24 VDC positive logic discrete output module with 16 points and 2 groups. Check that your backplane can supply 150 milliamps at 5 Volts. BluePLC Industrial offers this module and can help verify current lifecycle status and availability. Contact our team for assistance with your order.
