GE Fanuc IC693MDL740 Positive Logic Output Module for Series 90-30 PLCs

Product Introduction

When a manufacturing line requires reliable control of multiple DC-powered devices like contactors, relays, or pilot lamps, the GE Fanuc IC693MDL740 delivers a robust solution. This positive logic output module, part of the Series 90-30 family, provides sixteen sourcing outputs with 0.5 Ampere capacity per channel. Engineers choose this module for its straightforward integration and consistent performance in industrial automation environments. The IC693MDL740 operates within a voltage range of 12 to 24 volts DC (+20%, –15%), making it versatile for various control systems.

Technical Specifications Breakdown

The IC693MDL740 features two groups of eight channels each, with a common power output terminal per group. Each channel sources current from the module common or positive power bus to the connected load. Key electrical characteristics include an inrush current of 4.78 Amperes for 10 milliseconds, a maximum output voltage drop of 1 volt, and ON response time of 2 milliseconds maximum. The module draws 110 milliamps from the 5-volt backplane bus when all outputs are active. Operating temperature ranges from 0 to 60 degrees Celsius, with storage from -40 to 85 degrees Celsius, and relative humidity tolerance of 5 to 95%.

Industry Applications

In automotive assembly lines, the IC693MDL740 controls solenoid valves and motor starters for precise part positioning. Its 0.5 Ampere per channel output handles multiple inductive loads without external amplification. For packaging machinery, this module energizes pilot lamps and buzzers to indicate machine status, leveraging the 2 Ampere per common surge capacity for 10 milliseconds during initial startup. The positive logic sourcing design simplifies wiring in systems where the load connects to the negative power bus.

Installation & Setup Guidance

Mount the IC693MDL740 into any available slot of a 5-slot or 10-slot Series 90-30 baseplate. Ensure the controller has sufficient memory to accommodate this 16-point output module. The module does not include internal fusing, so install external fuses on each output channel for overcurrent protection. Connect the user common terminal to the positive power bus and the load between the module output and the negative power bus. Verify the operating voltage matches the 12 to 24 VDC range before powering the system.

Maintenance & Reliability

The IC693MDL740 offers front panel LED indicators that show the actuated state of each channel and the module's operational status. Regularly inspect these LEDs during routine checks to identify faulty channels quickly. The module's 2 ms ON and OFF response times ensure fast switching, reducing wear on connected contactors and relays. Given its discontinued lifecycle status, stock spare modules from BluePLC Industrial to minimize downtime. Store the module within -40 to 85 degrees Celsius and 5 to 95% humidity to maintain reliability.

Compatibility & Integration

This module integrates seamlessly with GE Fanuc Series 90-30 PLCs, including 5-slot and 10-slot baseplates. It is compatible with various DC loads such as solenoids, motor starters, pilot lamps, and buzzers. The positive logic sourcing output works with loads connected between the module output and the negative power bus. For systems requiring additional channels, multiple IC693MDL740 modules can be installed as long as the controller memory supports them.

Selection Guide & Purchasing Advice

Before purchasing the IC693MDL740, verify your system's voltage requirements match the 12 to 24 VDC range. Confirm the baseplate slot availability and controller memory capacity. Since this module is discontinued, contact BluePLC Industrial for current stock and replacement options. BluePLC Industrial offers verified inventory and fast shipping for industrial automation parts, ensuring your production line stays operational.
