Bently Nevada 330104-14-19-10-11-00 3300 XL 8 mm Proximity Probe Overview

Product Introduction

When unexpected machine downtime strikes, the Bently Nevada 330104-14-19-10-11-00 3300 XL 8 mm Proximity Probe delivers reliable vibration and position monitoring to keep operations running. This probe is part of the trusted 3300 XL series, designed for non-contact measurement of shaft vibration and displacement in critical rotating equipment. With a Polyphenylene sulfide (PPS) probe tip and AISI 303 or 304 stainless steel case, it withstands harsh industrial environments while providing consistent performance. The armored M10 x 1 thread and 140 mm unthreaded length simplify installation in tight spaces, reducing labor costs and installation time.

Technical Specifications Breakdown

Key parameters of the 330104-14-19-10-11-00 directly impact measurement accuracy and system reliability:

- Probe Length and Resistance: The 1.0 meter (3.3 feet) probe has a nominal DC resistance of 7.59 ± 0.50 ohms from center conductor to outer conductor. This tight tolerance ensures consistent signal transmission, minimizing calibration drift and reducing long-term maintenance expenses.

- Power Requirements: The system requires -17.5 Vdc to -26 Vdc (or -23 Vdc to -26 Vdc with barriers) at 12 mA maximum consumption. Operating within this range avoids reduced linear range, preventing costly measurement errors that could lead to false alarms or missed faults.

- Output Resistance: With 50 Ω output resistance, the probe integrates seamlessly with standard monitoring systems, lowering integration complexity and associated engineering costs.

- Temperature Classification: The probe supports ambient temperatures from -55°C to +232°C (T1 classification), enabling use in high-temperature turbine or compressor applications without derating, thus extending service life and reducing replacement frequency.

Industry Applications

This proximity probe excels in several demanding scenarios:

- Steam and Gas Turbines: Continuous vibration monitoring detects early bearing wear or imbalance, preventing catastrophic failures that could cost millions in lost production and repairs.

- Centrifugal Compressors: The 1.0 meter cable length and armored construction suit tight installations where space is limited, reducing retrofit costs and downtime.

- Pumps and Motors: The probe's stainless steel case resists corrosion in wet or chemical environments, lowering total cost of ownership by avoiding premature replacement.

Installation & Setup Guidance

Proper installation maximizes probe life and measurement accuracy. The M10 x 1 thread with armor allows secure mounting in pre-drilled holes. Ensure the probe tip gap is set to 1.27 mm (50 mils) using the recommended AISI 4140 steel target for calibration. The FluidLoc cable and miniature coaxial ClickLoc connector with connector protector provide strain relief and environmental sealing, reducing signal noise and connection failures. Always verify that the power supply meets the -17.5 Vdc to -26 Vdc range to maintain linear output. Following these steps minimizes commissioning time and avoids costly rework.

Maintenance & Reliability

Routine inspection of the probe tip and cable integrity helps sustain performance. The PPS tip resists wear from debris, while the stainless steel case withstands vibration and thermal cycling. Check the connector for corrosion or damage periodically. Because the probe seals differential pressure with a Viton O-ring, verify the seal integrity in high-pressure applications. These simple checks prevent unexpected failures and extend the probe's operational life, directly improving return on investment.

Selection Guide & Purchasing Advice

Before ordering, confirm that the 330104-14-19-10-11-00 matches your system requirements: verify the 1.0 meter total length, M10 x 1 thread, and unthreaded length of 140 mm. The probe requires a compatible 3300 XL Proximitor sensor and extension cable for full system functionality. For current availability and lifecycle status, contact plcmatrix.com. As a trusted supplier of industrial automation components, plcmatrix.com offers this probe along with expert support to ensure you select the right part for your application, helping you avoid costly mismatches and delays.
