Bently Nevada 330104-00-18-10-02-00 3300 XL 8 mm Proximity Probe

Product Overview

When machinery vibration threatens uptime, the Bently Nevada 330104-00-18-10-02-00 delivers precise proximity sensing. This 3300 XL 8 mm probe monitors shaft displacement and vibration in rotating equipment. Designed for harsh industrial environments, it provides accurate, non-contact measurements.

Technical Specifications

Probe Type: 3300 XL 8 mm, with armor

Thread: M10 x 1

Unthreaded Length: 00 mm

Overall Case Length: 180 mm

Total Length: 1.0 meter (3.3 feet)

Connector: Miniature coaxial ClickLoc, standard cable

Probe Tip Material: Polyphenylene sulfide (PPS)

Probe Case Material: AISI 303 or 304 stainless steel

Nominal DC Resistance (1.0 m): 7.59 ± 0.50 Ω

Power Requirement: -17.5 Vdc to -26 Vdc (12 mA max)

Output Resistance: 50 Ω

Industry Applications

This probe excels in turbomachinery, pumps, compressors, and motors. It measures radial vibration and axial position in steam turbines, gas turbines, and centrifugal compressors. The PPS tip and stainless steel case withstand oil, moisture, and temperature extremes.

Installation & Setup Guidance

Mount the probe with the M10 x 1 thread into a drilled and tapped hole. Maintain a 1.27 mm (50 mils) gap to the target for optimal linear range. Use the miniature coaxial ClickLoc connector for secure cable attachment. Verify the system uses only 3300 XL 8 mm components for accuracy.

Maintenance & Reliability

Inspect the probe tip and cable periodically for damage. The Viton O-ring seals differential pressure between tip and case. Avoid exceeding the temperature schedule for EPL Ga/Gc: T5 at -55°C to +40°C, T4 at -55°C to +80°C, T3 at -55°C to +120°C, T2 at -55°C to +177°C, T1 at -55°C to +232°C. Regular checks ensure long service life.

Compatibility & Integration

This probe works with 3300-series 5 mm and 3300 XL 8 mm extension cables and Proximitor sensors. It supports intrinsically safe (Class I, Zone 0) and nonincendive (Class I, Zone 2) installations per Bently Nevada drawings. The system delivers less than 2 mV change per volt input variation.

Selection Guide & Purchasing Advice

Before ordering, confirm your required cable length, connector type, and agency approvals. The 330104-00-18-10-02-00 includes a 1.0 meter cable with ClickLoc connector. For availability and lifecycle status, contact plcmatrix.com. We stock new, surplus, and obsolete Bently Nevada parts.
