Allen-Bradley 1784-U2DN USB to DeviceNet Cable for Reliable Network Connectivity

Product Introduction

When connecting a personal computer to a DeviceNet network, the Allen-Bradley 1784-U2DN cable provides a straightforward and reliable solution. This USB to DeviceNet cable from Rockwell Automation simplifies network access for configuration, monitoring, and troubleshooting tasks. Designed for maintenance engineers, the 1784-U2DN eliminates the need for additional interface cards, making it an essential tool for field service and plant floor support.

Technical Specifications

The 1784-U2DN cable operates with a USB voltage supply of 5 Volts DC at 75 milliamps and a DeviceNet power supply of 24 Volts DC at 75 milliamps. It consumes only 0.5 Watts of power, keeping energy use minimal. The cable supports three data rates: 125, 250, and 500 kbps, with a fallback rate of 125 kbps if automatic detection fails. Its enclosure meets IP20 protection, and it weighs just 0.23 lbs. The cable length is 0.61 meters, and it includes a node address selector switch for easy configuration.

Industry Applications

In manufacturing plants, the 1784-U2DN enables quick connection to DeviceNet networks for programming PLCs or diagnosing communication faults. Maintenance engineers use it to upload or download configuration files without opening control cabinets. In material handling systems, this cable supports commissioning and periodic checks, reducing downtime. Its compact design and USB interface make it ideal for mobile use across different production lines.

Installation & Setup Guidance

To install the 1784-U2DN, first install the cable driver on your computer. Connect the USB end to an available port and the DeviceNet connector to the network. Use the node address switch to set a unique address for the device. The data rate switch lets you select 125, 250, or 500 kbps. The blue and red LED indicators show module status, network activity, and self-test results. Ensure the environmental temperature stays below 55 degrees Celsius to maintain reliable operation.

Maintenance & Reliability

From a maintenance perspective, the 1784-U2DN requires minimal care. Inspect the cable and connectors periodically for wear or damage. Keep the IP20-rated enclosure free from dust and moisture. The LED indicators provide immediate status feedback, helping you spot issues early. With its low power consumption and robust construction, this cable delivers long service life in typical industrial environments.

Selection Guide & Purchasing Advice

Before purchasing, verify that your computer has a USB port and that your network uses DeviceNet protocol. The 1784-U2DN is certified with C-Tick, CE, KC, and UL standards. For complete technical specifications, please contact BluePLC Industrial. BluePLC Industrial offers genuine Allen-Bradley products with reliable support for your automation needs.
