Allen-Bradley 1771-IC PLC-5 Digital DC Input Module 8 Inputs

Product Introduction

When electrical noise and contact bounce cause false triggers and unplanned downtime in industrial control systems, the Allen-Bradley 1771-IC provides a robust solution. This digital DC input module is part of the 1771 series used in PLC-5 systems. It features input filtering that suppresses voltage transients, reducing electrically-related downtime and extending product life. The module is shipped in a static-shield bag for protection against electrostatic discharge.

Technical Specifications Breakdown

The 1771-IC operates with a voltage category of 10-60 Volts DC, sink (source load), making it suitable for a wide range of DC sensors and switches. Its DC operating voltage range is 42-56 Volts, ensuring stable performance within typical industrial power supplies. The module draws 74 milliamperes from the backplane, a modest load that minimizes power supply strain. Key performance specs include a maximum off-state current of 3.7 mA and typical signal delays of 17 (±7) ms on and 20 (±7) ms off due to digital filtering. These parameters ensure reliable signal detection even in noisy environments.

Industry Applications

The 1771-IC excels in applications requiring reliable DC input sensing. Common use cases include monitoring limit switches on conveyor systems, reading float switches in tank level control, and interfacing with DC proximity sensors in material handling. The input filtering is particularly valuable in high-noise environments like welding cells or motor control centers, where electrical noise can cause false readings. For 3-wire sensor applications, the off-state leakage must not exceed 4 mA to ensure proper operation.

Installation & Setup Guidance

Install the 1771-IC in any slot of a 1771 I/O chassis. Use wiring arm 1771-WN for field wiring connections. The module works with 2-wire and 3-wire devices including DC proximity switches, limit switches, float switches, pushbuttons, photoelectric sensors, and selector switches. Ensure the power supply provides at least 74 mA of backplane current to the module. For 3-wire devices, verify the off-state leakage current is below 4 mA to prevent false on-states.

Maintenance & Reliability

The conformal coating on the 1771-IC protects against moisture and contaminants, enhancing reliability in harsh environments. Periodic inspection of wiring connections and module seating is recommended. The input filtering doubles or triples product life by reducing stress from voltage transients. No routine calibration is required; however, verify proper operation during system maintenance intervals.

Compatibility & Integration

The 1771-IC is designed for Allen-Bradley PLC-5 systems using the 1771 I/O backplane. It is compatible with 1771 series power supplies and chassis. The module works with a wide range of DC input devices, making it a versatile choice for system expansions or replacements. For complete technical specifications for the 1771-IC, please contact BluePLC Industrial.
