Allen-Bradley 1734-IB4D POINT I/O Digital DC Sinking Input Module with Diagnostics

Product Introduction

Industrial automation has evolved from simple relay controls to sophisticated, modular I/O systems that adapt to changing production demands. The Allen-Bradley 1734-IB4D input module represents this evolution as a key component of the POINT I/O 1734 series. This digital DC sinking input module combines diagnostics with compact design, making it suitable for modern control architectures. The 1734-IB4D offers 4 inputs labeled 0 through 3, each with a status indicator light for easy monitoring. Its open-style enclosure supports horizontal or vertical mounting, simplifying installation in crowded panels.

Technical Specifications Breakdown

The 1734-IB4D operates at 24 Volts DC input voltage with a maximum input current of 5 milliamps. It draws 50 milliamps from the POINTBus and dissipates 1.9 BTU/hour of power. The module weighs approximately 1.14 ounces and measures 2.2 x 0.47 x 2.97 inches. It accepts a power input range of 10 to 28.8 Volts DC, with a nominal 24 Volts DC. The operating temperature spans -20 to 55 degrees Celsius (-4 to 131 degrees Fahrenheit). The 1734-IB4D features a Removable Terminal Block (RTB) mounted on the base, with terminal base screw torque of 0.8 N-m (7 pounds per inch). Maximum POINTBus current reaches 75 mA at 5 Volts DC, and maximum power dissipation at 28.8 Volts DC is 1.0 Watt (3.4 BTU/hour).

Industry Applications

Manufacturing facilities use the 1734-IB4D for discrete sensing tasks such as monitoring limit switches, push buttons, and proximity sensors. In packaging lines, the module's diagnostics help identify input faults quickly, reducing downtime. The wide temperature range allows deployment in both conditioned control rooms and harsher environments like warehouses or outdoor enclosures. The compact form factor fits into distributed I/O cabinets where space is limited.

Installation & Setup Guidance

Mount the 1734-IB4D on a POINT I/O mounting base using the keyswitch position. Connect field wiring to the Removable Terminal Block (RTB) with screw torque of 0.8 N-m (7 pounds per inch). The module supports horizontal or vertical orientation. Ensure the power input stays within 10 to 28.8 Volts DC. Use the status indicators on each input to verify proper wiring and signal presence. For network integration, the 1734-IB4D works with ControlNet, DeviceNet, EtherNet/IP, and other open networks.

Maintenance & Reliability

Routine inspection of the 1734-IB4D involves checking the status indicators and verifying input signals match expected states. The open-style enclosure allows visual inspection without removal. Keep the module within its operating temperature range of -20 to 55 degrees Celsius to ensure reliable performance. The diagnostics feature helps identify channel faults early, supporting proactive maintenance. No special cleaning procedures are required; simply follow standard industrial equipment care guidelines.

Compatible Systems & Integration

The 1734-IB4D integrates seamlessly with Rockwell Automation controllers via POINT I/O backplane. It supports multiple network protocols including ControlNet, DeviceNet, EtherNet/IP, and other open networks. This flexibility allows connection to Allen-Bradley CompactLogix, ControlLogix, and other PLC platforms. The module uses a single keyswitch position for proper alignment on the mounting base.

Selection Guide & Purchasing Advice

Before ordering the 1734-IB4D, verify your system's power supply can deliver 24 Volts DC and the POINTBus current of 50 milliamps. Confirm the mounting base and RTB are compatible. For complete technical specifications, contact BluePLC Industrial. BluePLC Industrial offers genuine Allen-Bradley 1734-IB4D modules with expert support to ensure correct selection and integration.
