Allen-Bradley 1734-8CFGDLX POINT I/O Configurable Digital Module

Product Overview

When distributed control demands both flexibility and local intelligence, the Allen-Bradley 1734-8CFGDLX POINT I/O module delivers. This 8-channel configurable digital I/O module from Rockwell Automation integrates DeviceLogix Smart Component Technology, enabling logic solving directly at the I/O level. For maintenance engineers, this means reduced dependency on a central controller and faster response to field events. The 1734-8CFGDLX supports 24 Volts DC operation and offers eight self-configuring points that can function as either inputs or outputs, adapting to changing process requirements without hardware swaps.

Technical Specifications

Based on available data, the 1734-8CFGDLX operates with an input current range of 2 to 5 milliamps. The module draws 100 mA from the POINTBus at 5 Volts DC and dissipates a maximum of 2.6 W (8.9 BTU/hour at 28.8 Volts DC). Each input channel has an independently adjustable debounce time in millisecond intervals, with a default of 1000 milliseconds. The module is rated for an operating temperature of -20 to 55 degrees Celsius and mounts on a standard DIN rail. Its open-style enclosure allows for efficient heat dissipation in industrial cabinets.

Industry Applications

The 1734-8CFGDLX excels in material handling, packaging, and assembly lines where rapid reconfiguration is common. For example, in a conveyor sorting system, each module can independently read sensor inputs and control actuators, reducing scan cycle delays. The DeviceLogix capability allows the module to continue basic operations even if communication with the main PLC is temporarily lost, minimizing downtime. Maintenance engineers appreciate this resilience because it simplifies troubleshooting and keeps production running.

Installation & Setup Guidance

Mount the 1734-8CFGDLX onto a DIN rail using the compatible terminal base units: 1734-TOP, 1734-TOPS, 1734-TB, or 1734-TBS. You can install the module either before or after the base is mounted. The module supports removal and insertion under power (RIUP) when using the POINTBus backplane with auto-address and auto-baud functions. For reliable service, ensure the input voltage remains within 11 Volts DC minimum to 24 Volts DC nominal. Use twisted-pair wiring for the DeviceLogix network to minimize electrical noise.

Maintenance & Reliability

From a maintenance perspective, the 1734-8CFGDLX offers several reliability advantages. Its solid-state design eliminates mechanical wear points common in relay-based I/O. The module's open enclosure and wide operating temperature range (-20 to 55 degrees Celsius) suit harsh industrial environments. To maximize service life, periodically inspect the DIN rail mounting and terminal base connections for signs of vibration loosening. Verify that the ambient temperature stays within the rated range and that the enclosure is free from excessive dust or moisture. The module's low power dissipation (2.6 W) reduces thermal stress on adjacent components.

Compatibility & Integration

The 1734-8CFGDLX integrates seamlessly with ControlNet, DeviceNet, or EtherNet/IP networks using the POINTBus backplane. It supports ODVA pre-defined produce and consume assemblies for standard operation. When DeviceLogix is enabled, the module can run standalone logic or operate in peer-to-peer mode with automatic I/O data production—no master controller required. This flexibility makes it a drop-in upgrade for existing POINT I/O systems and simplifies expansion of distributed control architectures.

Selection Guide & Purchasing Advice

Before ordering the 1734-8CFGDLX, verify your system's power supply can deliver 100 mA at 5 Volts DC via the POINTBus. Confirm that your terminal base unit is one of the compatible models listed above. For complete technical specifications not covered here, please contact BluePLC Industrial. Our team can help you verify lifecycle status, availability, and any required accessories. BluePLC Industrial is a trusted supplier of Allen-Bradley automation components, offering fast shipping and expert support for your maintenance and upgrade projects.
