Allen-Bradley 1606-XLS480E Essential Power Supply for Industrial Systems

Product Overview

When your industrial control system demands a stable and efficient power source, the Allen-Bradley 1606-XLS480E delivers. This essential power supply from the 1606 series of switched mode power supplies supports both AC and DC converter applications, ensuring broad compatibility across diverse setups. With a nominal output voltage of 24 Volts and a maximum output current of 20 Amps, it provides 480 Watts of reliable power for your critical loads.

Technical Specifications Breakdown

The 1606-XLS480E handles AC input voltages from 100 to 240 Volts AC and DC input voltages from 110 to 150 Volts DC, making it suitable for global installations. Its output voltage adjustment range of 24 to 28 Volts allows fine-tuning for specific equipment needs. The unit achieves a typical efficiency rating of 93.90%, minimizing energy waste and reducing operating costs. A 50% output power reserve ensures consistent performance during peak demand periods, while the typical power factor of 0.9 optimizes energy usage.

Industry Applications

In manufacturing plants, the 1606-XLS480E powers PLCs, sensors, and actuators, maintaining uptime even with fluctuating line conditions. For process control systems, its wide ambient operating temperature range of -13 to 158 degrees Fahrenheit ensures reliable operation in harsh environments. The generous output power reserve makes it ideal for systems with intermittent high loads, such as motor starters or solenoid banks.

Installation & Setup Guidance

Mount the 1606-XLS480E on a standard DIN rail in a clean, ventilated enclosure. Ensure adequate airflow around the unit to maintain its rated efficiency. Connect the AC or DC input according to the voltage range specified on the label. Adjust the output voltage using the trim potentiometer if your application requires a voltage between 24 and 28 Volts. Always verify polarity and secure all connections before powering up.

Maintenance & Reliability

Periodically inspect the power supply for dust accumulation and ensure ventilation paths remain clear. The high 93.90% efficiency reduces heat generation, extending component life. Check input and output connections for tightness during routine maintenance. With proper care, the 1606-XLS480E delivers years of dependable service in continuous-duty applications.

Selection Guide & Purchasing Advice

Before ordering, confirm your system requires a 24 Volt DC supply with up to 20 Amps of current. Verify that your input voltage matches one of the supported ranges (100-240 VAC or 110-150 VDC). The 1606-XLS480E is available now at BluePLC Industrial. Contact our team for current lifecycle status and availability to ensure this model meets your project timeline.
