Allen-Bradley 1560-PDP2 PROFIBUS to SCANport Communication Adapter

Product Overview

The Allen-Bradley 1560-PDP2 is a PROFIBUS to SCANport communication adapter designed to bridge SCANport devices with PLCs or other DP protocol networks. Part of the SMC-Flex product line, this adapter enables seamless integration of drives and motor controllers into PROFIBUS DP systems. It supports up to 32 parameter values and operates at a maximum baud rate of 12 M, making it suitable for high-speed industrial communication.

Technical Specifications

Key specifications for the 1560-PDP2 include:

Input Voltage: 85-264 Volts AC

Frequency: 45-63 Hertz

Baud Rate: 12 M

Parameter Values: Up to 32

DIP Switch Address Range: 1 to 63

Mounting: DIN Rail

Weight: 225.00 lbs (102.06 kg)

The adapter consumes 65 milliamps at 24 Volts DC and operates in a temperature range of 0 to 50 degrees Celsius. It features red and green status LED indicators for PROFIBUS and SCANport status.

Comparison with Similar Products

Compared to other SCANport adapters, the 1560-PDP2 stands out with its PROFIBUS DP slave mode and SPC3 chipset. While some adapters support fewer nodes, the 1560-PDP2 can handle up to 126 nodes with 3 repeaters. Its input voltage range of 85-264 Volts AC provides flexibility for global installations, and the DIP switch configuration allows quick address setting from 1 to 63. Unlike simpler adapters, it supports three parity setups: none, odd, and even.

Industry Applications

The 1560-PDP2 is ideal for manufacturing facilities that use Allen-Bradley SCANport devices such as the 1336 Plus, 1397, 1305, and SMP3 drives. It enables centralized control and monitoring via PROFIBUS DP networks, reducing wiring complexity and improving system reliability. Common applications include conveyor systems, pump control, and material handling where high-speed parameter access is critical.

Installation & Setup Guidance

Mount the 1560-PDP2 on a DIN rail using the included clip. Configure the slave address via DIP switches (1-63) before powering up. Connect the PROFIBUS DP network to the 9-pin D-shell connector (RS-232, RS-422, or RS-485). Ensure the adapter is protected from water sprays as it has an open enclosure. Verify the input voltage is within 85-264 Volts AC and frequency between 45-63 Hertz.

Compatibility & Integration

The 1560-PDP2 is fully compatible with Allen-Bradley SCANport devices including the 1336 Plus, 1397, 1305, and SMP3. It integrates with any PROFIBUS DP master PLC or controller. The adapter supports up to 32 parameter values for command, control, and reference information, with a pre-assigned map for easy setup.

Selection Guide & Purchasing Advice

Before purchasing the 1560-PDP2, verify your system voltage and frequency requirements. Ensure your PROFIBUS network supports the 12 M baud rate and that you have a DIN rail mounting location. Contact BluePLC Industrial for current availability and lifecycle status. BluePLC Industrial is a trusted supplier of Allen-Bradley automation components.

For complete technical specifications for the 1560-PDP2, please contact BluePLC Industrial.
