Allen-Bradley 150-F60NCR SMC-Flex Solid State Controller 60A 40Hp

Product Introduction

When a manufacturing facility faces the challenge of controlling large induction motors with minimal mechanical stress and maximum energy efficiency, the Allen-Bradley 150-F60NCR SMC-Flex solid state controller provides a proven solution. This module belongs to the SMC-Flex product line, a family known for robust motor management in industrial automation. With an open enclosure design, the 150-F60NCR integrates seamlessly into control panels, delivering precise solid-state motor control for demanding applications.

Technical Specifications

The Allen-Bradley 150-F60NCR offers a controller rating of 60 A and 40 Hp at 460V AC, making it suitable for medium-sized motors. It accepts an input line voltage of 200-575V AC, 3-phase, at 50 and 60 Hz, providing flexibility across global power systems. The control voltage is 24V AC/DC for units rated 5-480 A, ensuring compatibility with standard industrial control circuits. The rated voltage is 500/575V AC. Weighing 20.00 lbs (9.07 kg), this solid state controller is built for durability in industrial environments.

Industry Applications

In a typical automotive assembly line, conveyors and pumps require smooth acceleration to prevent product damage and reduce wear on mechanical components. The 150-F60NCR delivers controlled starting and stopping, minimizing torque spikes and extending equipment life. Similarly, in HVAC systems for large commercial buildings, this controller manages fan and compressor motors, optimizing energy consumption while maintaining precise airflow. Its wide input voltage range makes it adaptable to facilities operating on different regional power standards.

Installation & Setup Guidance

Mount the 150-F60NCR securely inside an appropriate electrical enclosure, ensuring adequate ventilation for heat dissipation. Connect the 3-phase input line voltage (200-575V AC) to the designated terminals, observing proper phase rotation. Wire the control voltage (24V AC/DC) to the control circuit terminals as per the wiring diagram provided in the product manual. Verify that all connections are torqued to manufacturer specifications before applying power. Always follow local electrical codes and safety regulations during installation.

Selection Guide & Purchasing Advice

Before ordering the 150-F60NCR, confirm that your motor's full-load current does not exceed 60 A and that the horsepower rating aligns with your application requirements. Verify that the available input power matches the 200-575V AC, 3-phase specification. For applications requiring additional features such as communication modules or bypass contactors, consult the SMC-Flex accessories catalog. BluePLC Industrial stocks the 150-F60NCR and can provide current availability and pricing. Please verify lifecycle status with BluePLC Industrial before ordering to ensure timely delivery.
